API Standard 7 5/8" Float Shoe with Multiple Flank Jets and 304 Stainless Steel Construction for Cementing Float Equipment

7 5/8" Float Shoe

304 Stainless Steel Float Shoe

Multiple Flank Jets Float Shoe

Luogo di origine:

Jiangsu, Cina

Marca:

SWS

Certificazione:

API ISO

contattici

Richieda una citazione

Dettagli del prodotto

Misurare:

7 5/8"

Nod od:

7 5/8"

Abolo ID:

6 1/4"

Min noia:

2 3/8"

Tipo di filo:

LCSG da 7 pollici

Valutazione della pressione:

3626 lb/in²

Tipo di valvola:

singola valvola

Materiale:

Acciaio inossidabile acciaio al carbonio/304

Peso:

5 kg

Tipo di elaborazione:

Forgiatura

Componenti principali:

Valvola

Tipo di connessione:

LTC/BTC

Norma dell'API:

K55

Tipo di design:

Naso eccentrico

Jet di fianco:

Multiplo

Prodotti relativi

2-13/16 Inch Inside Diameter 6-3/4 Inch Outside Diameter Drill Collar in Oil and Gas Industry

Ottenga il migliore prezzo

159.5 mm Bevel Diameter 3.18:1 Bending Strength Ratio 9150 or 9450 mm Length Drill Collar

Ottenga il migliore prezzo

NC46-62(4IF) 158.8 mm Outside Diameter Drill Collar for Oil Well Drilling Oil Field Equipment

Ottenga il migliore prezzo

158.8 mm Outside Diameter 71.4 mm Bevel Diameter 9150 or 9450 mm Length Drill Collar

Ottenga il migliore prezzo

contattici

86-519-83553967

Leo@service-js.com

86-519-83553967

Contatto ora

Descrizione di prodotto

API Standard Drilling K55 LTC/BTC 7 5/8" Single Valve Eccentric Nose Float Shoe with Multiple Flank Jets

Product Specifications

Name	Size(in)	Bore O.D.(in)	Bore I.D.(in)	Min Bore Parameter(in)	Thread Type	lb(in2)
Float Collar	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
Float Shoe	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
