API 5-1/2 139.7mm Carbon Steel Float Shoe for Hand Well Drilling with 70MPa High Flow Valves

API 5-1/2 Float Shoe

139.7mm Cementing Float Equipment

70MPa Nose Float Shoe

Luogo di origine:

Jiangsu, Cina

Marca:

SWS

contattici

Richieda una citazione

API 5-1/2 139.7mm Carbon Steel Float Shoe for Hand Well Drilling with 70MPa High Flow Valves

Dettagli del prodotto

Dimensione:

50*30*30

Peso:

10 kg

Componenti principali:

Valvola

Tipo di valvola:

Valvola singola e doppia

Tipo di elaborazione:

Forgiatura

Specifiche:

2-3/8 ~ 20"

Tipo di filo:

BTC\LTC\ Fatto speciale\EU\NU

Grado in acciaio:

N80\L80\P110

Nod od:

6 "

Abolo ID:

4 3/4"

Min noia:

Tipo di filo:

5 1/2 "LCSG

Valutazione della pressione:

70MPA

Valutazione della temperatura:

204°C

Dimensione della valvola:

70 mm e 90 mm

Prodotti relativi

API Standard 114.3mm Float Shoe and Float Collar with 150°C and 204°C Seals for Oilfield Drilling

Ottenga il migliore prezzo

API Standard Nose Float Shoe Cementing Float Equipment with 150°C and 204°C Seals for Oilfield Drilling

Ottenga il migliore prezzo

API 5CT 7-5/8" L80 BTC/LTC Eccentric Multiple Flank Jets Aluminum Alloy Float Shoe for Cementing Tool

Ottenga il migliore prezzo

Testa di cementazione a doppia spina ad alta pressione API 5CT personalizzabile con pressione di lavoro di 35 MPa e garanzia di 1 anno

Ottenga il migliore prezzo

contattici

86-519-83553967

Leo@service-js.com

86-519-83553967

Contatto ora

Descrizione di prodotto

API 5-1/2 139.7mm Hand Well Drilling Equipment Float Shoe Carbon Steel Nose Float Shoe

Product Specifications

Name	Size(in)	Bore O.D.(in)	Bore I.D.(in)	Min Bore Parameter(in)	Thread Type	lb(in2)
Float Collar	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
Float Shoe	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626

Product Description

Float equipment serves as the backbone of casing equipment used during primary cementing operations. Float equipment guides the casing to total depth and prevents contaminated mud from entering the casing. Also, it provides a landing point for casing wiper plugs, reinforces the lower end of the casing string, and ensures great accuracy of cement slurry displacement.

Key Features

Hi Flow valves to reduce fluid erosion and minimize pressure drop
Hi Flow valves are manufactured in two sizes: 70mm and 90mm
PDC drillable composite plastic materials used for the valve components
Standard seal rated to 150°C with optional 204°C seal
Valve body molded with fibre phenolic, 70MPa and 204°C seal
Spring purchased from Canada Victory Spring Company, phosphor bronze C510 material, high restoring force and drillable
Plunger seal top molded with HNBR, 70MPa and 204°C seal
