Cementing Float Equipment for Well Drilling with Single Double Valve

cementing float equipment for well drilling

single valve cementing float equipment

double valve cementing float equipment

Luogo di origine:

Cina

contattici

Richieda una citazione

Cementing Float Equipment for Well Drilling with Single Double Valve

Dettagli del prodotto

Peso:

100 kg

Componenti principali:

Valvola

Tipo di valvola:

Valvola singola e doppia

Tipo di macchina:

Strumento di perforazione

Tipo di elaborazione:

Forgiatura

Dimensione del collare galleggiante:

5 1/2 ", 7", 9 5/8 ", 13 3/8"

Collar galleggiante a pasta OD:

6 ", 7 5/8", 10 5/8 ", 14 3/8"

Float Collar foro ID:

4 3/4 ", 6 1/4", 8 5/8 ", 12 3/8"

Float Collar Min Abod:

2 ", 2 3/8"

Tipo di filo con colletto float:

5 1/2 "LCSG, 7" LCSG, 9 5/8 "LCSG, 13 3/8" LCSG

Pressione del colletto galleggiante:

4351, 3626 lb/in2

Dimensione della scarpa galleggiante:

5 1/2 ", 7", 9 5/8 ", 13 3/8"

Scarpa galleggiata a piolo:

6 ", 7 5/8", 10 5/8 ", 14 3/8"

ID con foro di scarpa galleggiante:

4 3/4 ", 6 1/4", 8 5/8 ", 12 3/8"

Float shoe min abod:

2 ", 2 3/8"

Prodotti relativi

LTC 5-1/2 N80 Cementamento di proiettili per pozzi di petrolio o di gas

Ottenga il migliore prezzo

LTC 5-1/2 N80 Cementamento Reamer Float Shoe per pozzo di petrolio o pozzo di gas

Ottenga il migliore prezzo

LTC 5-1/2 N80 Cementamento di una scarpa di galleggiamento eccentrica per pozzo di petrolio o di gas

Ottenga il migliore prezzo

LTC 5-1/2 N80 Cementamento a getto di scarico

Ottenga il migliore prezzo

contattici

86-519-83553967

Leo@service-js.com

86-519-83553967

Contatto ora

Descrizione di prodotto

Innovative Oil Field Equipment Enhanced Wellbore Integrity with Advanced Cementing Float Technology

Product Specifications

Attribute	Value
Warranty	1 Year
Weight (KG)	100
Core Components	Valve
Valve type	single valve & double valve
Machine Type	Drilling Tool
Processing Type	Forging
Use	Well Drilling
Condition	New
Marketing Type	Ordinary Product
Warranty of core components	1 Year
Applicable Industries	Manufacturing Plant

Product Description

Float equipment serves as the backbone of casing equipment used during primary cementing operations. This essential component guides the casing to total depth and prevents contaminated mud from entering the casing. Additionally, it provides a landing point for casing wiper plugs, reinforces the lower end of the casing string, and ensures precise accuracy of cement slurry displacement.

Technical Specifications

Name	Size(in)	Bore O.D.(in)	Bore I.D.(in)	Min Bore Parameter(in)	Thread Type	lb(in2)
Float Collar	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
Float Shoe	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626

Company Profile

Our Factory

Product Images

Exhibition

Certifications

Product Packaging

Frequently Asked Questions

Q1: When can I get the price?

We typically provide quotes within 24 hours of receiving your inquiry. For urgent requests, please indicate this in your email for priority handling.

Q2: Could I have prices of your products?

Absolutely. Please send us your inquiry via email, and we'll respond within 24 hours.

Q3: Can I get a lower price if I order large quantities?

Yes, we offer volume discounts for larger quantity orders.

Q4: Do you inspect the finished products?

Yes, our QC department conducts thorough inspections at each production stage and performs final checks before shipping.

Q5: What about the lead time for mass production?

Production timelines vary based on order quantity and seasonal demand. We'll provide specific lead times when processing your order.
